Built in house at WCFab carrying a LIFETIME WARRANTY against bending or breaking (to original purchaser). Traction bars are a necessary upgrade when increasing the horsepower on your diesel truck or towing heavy to prevent the axle from twisting which can lead to broken u-joints, pinion yokes, driveshafts, and even twisted axle housings. Our traction bar brackets bolt on to the bottom of the axle tube via the axle u-bolts and weld to the frame on the front end. We use a high quality RockJock rebuild-able and grease-able Johnny Joint heim connection at the frame to allow for adjustment of torsion on the axle or if you raise/lower the rear of your truck. At the axle connection we use a heavy duty Poly Urethane Bushing for decreased noise and vibration which is common complaint if a solid heim is used on both ends. Grade 8 hardware connects the bars to the mounts on the frame and axle. We complete our traction bar kit with our professional in house powder coat process in your color choice and comes standard with a epoxy Primer base coat before the final color which increases corrosion resistance by more than ten times compared to just your standard powder single coat application. 100% bolt on DIY installation option for Crew Cab Short Bed models. All other cab and bed configurations require frame modification and welding for proper installation. Welding front mounts on all competition applications is recommended for maximum strength.
This kit includes 60" long bars for Regular Cab Long Bed, Extended Cab Short Bed and Crew Cab Short Bed Models
Wehrli Custom Fab Traction Bar Kit, 60 in., 20-25 Chevy & GMC Duramax RCLB/CCSB/ECSB, Candy Teal
Durable Custom Powder Coat Finish with Epoxy Primer Base Coat for superior corrosion resistance
Wehrli 20-24 Chevy & GMC Duramax RCLB/CCSB/ECSB 60in. Traction Bar Kit - Candy Teal
Traction Bar Kit, 60 in., 20-25 Chevy & GMC Duramax RCLB/CCSB/ECSB, Candy Teal
For Regular Cab Long Bed, Double Cab Short Bed and Crew Cab Short Bed Models
LIFETIME WARRANTY against bending or breaking (to original purchaser)
100% bolt on DIY installation option for Crew Cab Short Bed models
Frame side bolt (CCSB only) or weld on mounts
Traction Bars 60 in. 20-25 GM HD Candy T
This kit is for 2020-2025 GM HD Trucks
Axle side bolt on mounts
Suspension Traction Bar
RockJock Johnny Joints
TracBars 60 20-25 CT
60" Heavy Duty Bars
Grade 8 Hardware
Poly Bushings
Made in USA
