ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty offers unparalleled performance and ride quality while giving the vehicle clearance for 38” Tall tires. This system comes complete with ICON 2.0 Aluminum Series Shocks, Dual Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, ICON's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.
APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
APPLICATION NOTE #56: Rear Add-A-Leaf Required For Truck To Sit Level When Using 6” Block Included In Kit
Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
APPLICATION NOTE #21: NOT APPLICABLE ON VEHICLES EQUIPPED WITH A MANUAL TRANSMISSION
100% Bolt-on system - No drilling, cutting, or welding necessary
APPLICATION NOTE #6: SPRINGS ARE RATED FOR DIESEL ENGINES ONLY
2005-2007 FORD F-250/F-350 7" LIFT STAGE 1 SUSPENSION SYSTEM
ICON 05-07 Ford F-250/F-350 7in Stage 1 Suspension System
7” more travel from ride height to front bump stops
05-07 FORD F-250/F-350 7" STAGE 1 SUSPENSION SYSTEM
Lifetime guarantee that coil springs won’t sag
State of the art dual-rate coil spring
05-07 F-250/F-350 7" STAGE 1 SYSTEM
No drive shaft modifications needed
OEM Wheels & Tires Fitment: Yes
75% increase in wheel travel
No change in towing capacity
Less body roll than stock
Ships in multiple boxes
Clears 38" Tall Tires
Suspension Lift Kit
SUSPENSION SYSTEM
