This system is designed to lift your 2000-2005 Ford Excursion 5" in the front and provide room for 35” tires. This system uses custom progressive spring packs front and rear for ultimate ride quality, while providing 5" of lift. This system comes with a 1.75" bump stop spacer (not pictured) to prevent spring fatigue during the suspension cycle. Also included in this kit is 5” rear block kit, with 12” U-bolts for a leveled stance.
APPLICATION NOTE #1: FRONT U-BOLT NOTE: ALL FRONT SPRINGS COME COMPLETE WITH FRONT U-BOLTS, WASHERS, AND NUTS. WHEN ORDERING ANY FRONT SPRING SYSTEM FROM ICON VEHICLE DYNAMICS PLEASE SPECIFY MANUFACTURE YEAR.
Recommended Aftermarket Tires: 35" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #17: THESE ARE STAND-ALONE KITS AND ARE NOT TO BE USED IN CONJUNCTION WITH ANY OTHER AFTERMARKET KITS
APPLICATION NOTE #3: NO FRONT DRIVESHAFT MODIFICATION NEEDED. STOCK DRIVESHAFT IS FULLY FUNCTIONAL.
Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
100% Bolt-on system - no drilling, cutting or welding necessary for install
APPLICATION NOTE #6: SPRINGS ARE RATED FOR DIESEL ENGINES ONLY
ICON 00-05 Ford ExcursioICON 5in Suspension System
2000-2005 FORD EXCURSION 5" LIFT SUSPENSION SYSTEM
00-05 FORD EXCURSION 5" SUSPENSION SYSTEM
00-05 FORD EXCURSION 5" SUSP SYSTEM
No drive shaft modifications needed
OEM Wheels & Tires Fitment: Yes
Less body-roll than stock truck
No change in towing capacity
Durable powder coat finish
Increased wheel travel
Suspension Lift Kit
5" SPRING SUSP SYS
SUSPENSION SYSTEM
K45000-99
