ICON Vehicle Dynamics 2023-2024 Chevrolet Colorado WT, LT, and Z71 suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. This Stage 1 system includes vehicle-specific tuned 2.5” coilover shocks featuring an internal reservoir for exceptional cooling properties and ICON-engineered coil springs for superior vehicle “feel” through the range of travel. These coilovers, specifically designed for the narrower track width of these Chevrolet Colorado submodels, are also height adjustable for 1.75-2.5” of front lift over stock, allowing the use of larger, more aggressive wheel and tire combinations. Their longer than stock length improves performance by increasing front wheel travel while still being compatible with the stock front upper control arms. ICON 2.0 Aluminum Series internal reservoir rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear. The ICON Vehicle Dynamics 2023-2024 Chevrolet Colorado WT, LT, and Z71 Stage 1 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
ICON suspension systems lift your Colorado while improving ride quality and performance. With endless hours spent testing and tuning our suspension components and shocks, you’ll have the best suspension solution on the market.
Recommended Aftermarket Tires: 33" x 12.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
APPLICATION NOTE #55: Shocks are fully serviceable. Lift heights indicated are for a stock equipped vehicle.
APPLICATION NOTE #160: Will not fit GMC Canyon. Will not fit Chevrolet Colorado Trail Boss or ZR2
Vehicle specific tuned front and rear shocks for superior damping and vehicle control
Increased wheel travel and ride quality over stock with no change in towing capacity
2.0 Aluminum Series rear internal reservoir shocks with 5/8" polished shafts
100% Bolt-on system - no drilling, cutting, or welding necessary for install
Recommended Aftermarket Wheels: 17x8.5" w/ 5.46” Backspace / 18mm Offset
TECH NOTE: Rear shocks are compatible with 0-2" of rear lift over stock
Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts
Adjustable Coilovers from 1.75-2.5" of front lift height over stock
ICON 2023 Chevrolet Colorado 1.75-2.5in Stage 1 Suspension System
FK rod end bearings for extended longevity and minimal deflection
23-24 CHEVROLET COLORADO 1.75-2.5" STAGE 1 SUSPENSION SYSTEM
6061 Aircraft grade aluminum CNC machined components
High strength alloy CNC machined lower bar pin
Factory Wheels & Tires Fitment: Yes
Suspension Lift Kit
SUSPENSION SYSTEM
K73091
