The 2016-2023 Nissan Titan XD is an all new truck with a heavy-duty build that’s aimed to blend the lines between ½ ton efficiency and ¾ ton capability. With this in mind, ICON Vehicle Dynamics has developed a complete suspension system designed from the ground up for improved performance on and off-road, increased wheel travel over stock, and the best ride quality on the market. The Stage 3 system includes ICON 2.5 Series remote reservoir coilovers with CDC (Compression Damping Control) Valve technology, 2.5 Aluminum Series rear shocks with CDC Valve, Delta Joint upper control arms, rear lift blocks, and U-bolts. These products feature high-quality components such as ICON-designed coil springs, precision machined internals, FK Rod End bearings, and a vehicle-specific shock tune that translates to a ride quality that is second to none. The ICON Vehicle Dynamics 2016-2023 Nissan Titan XD Stage 3 suspension system is the best choice for those drivers looking to drastically enhance the capabilities of their truck off-road, improve handling characteristics on the road, and have the ability to customize their ride for the best performance in any situation.
This system features upper control arms with ICON's patented Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.
This system features upper control arms with ICON's patented Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.
ICON 2.5-3” suspension systems lift your Nissan Titan XD while improving ride quality and performance. With endless hours spent testing and tuning our suspension components and shocks, you’ll have the best suspension solution on the market.
2.5 Aluminum Series rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish
Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 4.75” Backspace / 0mm Offset
Vehicle specific tuned front and rear shocks for superior shock damping and control
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.00" Backspace / 0mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.00" Backspace / 0mm Offset
ICON CDC Valve allows quick and easy end-user compression adjustability
Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts
Increased ride quality over stock with no change in towing capacity
FK Rod End bearings for extended longevity and minimal deflection
APPLICATION NOTE #115: LIFT HEIGHTS BASED ON 4WD CREW CAB DIESEL
2016-UP NISSAN TITAN XD 3" LIFT STAGE 3 SUSPENSION SYSTEM
Approximately 32% increased front wheel travel over stock
ICON 2016+ Nissan Titan XD 3in Stage 3 Suspension System
6061 aircraft grade aluminum CNC machined components
16-UP NISSAN TITAN XD 3" STAGE 3 SUSPENSION SYSTEM
16-23 NISSAN TITAN XD 3" STAGE 3 SUSPENSION SYSTEM
Adjustable coilovers provide 2.5-3" of lift height
16-UP NISSAN TITAN XD STAGE 3 SUSP SYS
OEM Wheels & Tires Fitment: Yes
Fits 2WD / 4WD applications
Ships in multiple boxes
100% bolt-on system
Suspension Lift Kit
SUSPENSION SYSTEM
TITAN XD STAGE 3
K83033
