ICON Vehicle Dynamics V.S. 2.5 Series remote reservoir front coilover shocks are an incredible upgrade for the front end of the 2005-2023 Toyota Tacoma equipped with the Pro Comp 6” lift kit. These coilovers offer lift height adjustability, allowing fine tuning of ride height or the use of larger, more aggressive wheel and tire combinations. ICON’s Vehicle-specific shock length and valving along with the larger 2.5” shock body and increased piston area over stock components yield the maximum travel possible along with superior ride quality and suspension performance both on- and off-road. To better support the weight of additional accessories such as aftermarket front bumpers and winches, these coilovers include ICON engineered coil springs with an increased, 700 lbs/in spring rate, allowing for taller ride heights with increased front end weight. Remote reservoirs greatly increase shock oil volume and heat dissipation surface area to resist overheating and cavitation under hard use, which can lead to damper fade. ICON's exclusive Compression Damping Control Valves are included for precisely dialing in your suspension performance. CDCV controls fluid flow under compression, allowing you to achieve the perfect tune whether driving on the street, slow-crawling through the rocks or mobbing across the desert at full throttle. When paired with ICON 2.0 or 2.5 Aluminum Series rear shock absorbers vehicle control will be balanced front to rear, resulting in the best overall driving experience for your Toyota Tacoma.
These ICON coilovers feature 2.5 Series shocks and coil springs optimized for this application. The shock’s larger 2.5” body and increased piston area improves damping ability and ride characteristics across varying types of terrain.
APPLICATION NOTE #254: Requires compatible 6" subframe lift. Coilover length optimized for Pro Comp 6" lift but may also be compatible with kits from other manufacturers
TECH NOTE: 700lb/in spring rate only recommended for trucks with additional weight added to front end. See ICON Help Center for information.
APPLICATION NOTE #50: 700lb/in spring rate only recommended for trucks with additional weight added to front end
APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
ICON engineered coil springs with 700 lbs/in spring rate are more ideal for heavier equipped front ends
Height-adjustable coilovers with application specific length for fitment with Pro Comp 6" lift kits
Remote reservoirs maintain cooler operating temperatures during extended off-road use
ICON 2005+ Toyota Tacoma 2.5 Custom Shocks VS RR CDCV Coilover Kit w/Procomp 6in
ICON CDCV equipped for 10 settings of external compression damping adjustment
2005-UP TACOMA 2.5 VS RR CDCV COILOVER KIT W/ PROCOMP 6" LIFT 700LB COILS
APPLICATION NOTE #185: Will not fit 2WD Tacoma with 5 wheel lug studs
Corrosion resistant CAD plated shock bodies with 7/8" diameter shafts
FK rod end bearings for extended longevity and minimal deflection
Vehicle specific tuned for superior shock damping and control
Increased wheel travel and improved ride quality over stock
05-UP TACOMA 2.5 VS RR CDCV COILOVER KIT W PROCOMP 6"
05-23 TACOMA 2.5 VS RR CDCV COILOVER KIT W PROCOMP 6"
6061 Aircraft grade aluminum CNC machined components
05-UP TACO RR CDCV CO KIT W PROCOMP 6"
Fully rebuildable and re-tunable
TACOMA COILOVERS
58731C-700-CB
COILOVER KIT
Coilover Set
