Built from 6061-T6 billet aluminum, stainless steel, and heavy-duty 1 5/8-inch DOM steel tubing, BMR's CB005 Cradle Bushing Lockout Kit is designed to nearly eliminate cradle bushing deflection, which is one of the biggest causes of wheel hop. BMR's CB005s billet aluminum upper bushing lockout rings capture the inner bushing sleeve (front and rear) and the outer lip of the bushing cup on the cradle (front). The lower bushing locating washers (front) capture the bottom portion of the bushings inner sleeves. By capturing both parts of the bushings inner sleeves, movement on any plane (fore/aft, lateral, and vertical) is nearly eliminated. This assembly is completed with bolt-on cradle braces that replace the factory sheer plates. The large lug on the cradle side of the braces positively locates the cradle, ensuring it is perfectly centered under the car. The two bolts in the frame ensure the location of the cradle can't change under any form of driving.
BMR Suspension designed the CB005 Cradle Bushing Lockout Kit for any application. This 100% bolt-on kit use existing bolt holes and hardware, allowing for easy installation with simple hand tools.
Greatly reduces stock bushing deflection, wheel hop, and cradle deflection
CNC-machined 6061-T6 billet aluminum upper bushing lockout rings
BMR 15-17 S550 Mustang Cradle Bushing Lockout Kit - Red
CNC-formed stainless steel lower bushing support plates
Available in black hammertone and red powder coat
Adds a solid rear jacking point to each side
1 5/8-inch DOM steel tubing cradle braces
Laser-cut lower bushing support washers
Uses factory bolt holes and hardware
Cradle Bushing Lockout Kit, Level 2
Installs with simple hand tools
Suspension Subframe Bushing Kit
Fits 2024-Current S650 Mustangs
Fits 2015-2023 S550 Mustangs
Proudly designed in the USA!
Durable powder coat finish
1-2 hour installation time
Proudly made in the USA!
BMR Suspension - CB005R
Centers the rear cradle
No fabrication needed
100% bolt-on design
Cradle Bushing Kit
