Important excerpt from the ARP catalog regarding proper fastener installation: “The importance of tightening fasteners to their required preload cannot be emphasized enough. If a fastener is not preload cannot be emphasized enough. If a fastener is not tightened properly, the fastener will not apply the required preload on the application it is being used for and may become susceptible to failure. Conversely, if a fastener is over tightened and stretched too much, it becomes susceptible to failure by exceeding it’s maximum yield point.”
Manley Connecting Rod Bolt - Replacement Parts - Cap Screws 3/8" ARP 2000 - 1.500" UHL. For H-Beam Standard Weight, H-Lite Series and Pro Series I-Beam. Stretch .0058" to .0062" ARP2000 mat'l 55-65 w/oil 45-55 w/lube
Manley Bolt 3/8 2000 Material 1.500 Length Under Head-Pack of 4 (Compatible with Manley Rod 14024)
Underhead Length: 1.500 in. - Recommended Stretch (w/ ARP Lube): .0058-.0062 in. - Qty: 4
Premium ARP-manufactured rod bolts engineered for high clamp load and reliability
Provides consistent preload when installed using recommended stretch method
Precision thread rolling and heat treatment for maximum tensile strength
Ideal for high-horsepower, high-RPM street and racing applications
Manley Connecting Rod Bolt Set- 3/8" ARP 2000 1.500"
ROD BOLT SET-ARP2K 3/8 1.5 in.
Engine Connecting Rod Bolt
Rod Bolt Set
