The BVA-200s is a durable hand held battery and electrical system tester with an on-board 120 amp load for heavy use in a professional shop environment. This tester comes with a rugged anodized aluminum housing, rubber hand grip, and 6 gauge leads with heavy duty clamps. Performs a complete electrical system test in 82 seconds!
Patented Test Process And Algorithm Allowing Operators Of This Product To Rapidly Measure A Batterys Ability To Provide Adequate Cranking Power To Start The Vehicle Without The Need For Time Consuming Manual Electrical System Load Tests.
This Tester Has The Ability To Apply A Known Significant Load (True-Load) Directly Through The Tester Connections Allowing For A More Rapid And Accurate Test Of The Vehicles Battery, Starter, And Charging System By The Operator
This Provides The Ultimate In Accurate High-Speed Battery Testing When Paired With Autometers Advanced Digital Pulse Load Technology Process, Reducing The Margin Of Operator Error And Workload During The Diagnosis.
Automatically stores results of last 150 completed tests for easy review. Wirelessly communicates to optional test results printer via infrared or outputs to PC via AC-12 cable.
Tests 6V and 12V flooded and AGM batteries rated between 100-1600 CCA or 10-265 AH. Tests starting/charging circuits, discharged batteries, and detects bad cells.
Unlike competitor models, AutoMeter testers only require a single technician to run a full electrical system test due to our on-board 120 amp True Load cell.
Charging system test results measure alternator current output, voltage regulation, and diode ripple delivering a pass or fail result.
This eliminates the need to apply inconsistent loads, such as headlights, fans, etc.
True-Load - AutoMeter equipment is unique compared with other products on the market
Intuitive menu driven operation, transmitted via backlit LCD screen for ease of use.
16 Gauge, 20" leads with professional grade clamps that are easily field serviceable
which makes our products easier to use and more accurate.
English and Spanish language menus and test results.
Advanced Digital Pulse Load (DPL) technology
Autometer Starting/Charging System Analyzer
STARTING/CHARGING SYSTEM ANALYZER
START/CHRG SYS TSTR
Battery Tester
TEST EQUIPMENT
